Features

• Sheer power and high torque take on a whole new meaning with the new high-output CUprex motor. It offers performance-optimized digital electronics and newly developed control technology. Its speed is continuously variable according to the nature of the material and application.
• The saw´s handling and behavior are refined by smooth starting, constant speeds under load, speed reduction and overload protection.
• The exemplary design of the MKS 130 EC embraces extremely rugged and high-quality materials, including the lightweight magnesium die-cast housing and impact-resistant, fiber glass-reinforced plastic components. Most of the surfaces that are conventionally exposed to dust or chips have been eliminated.
• The MKS 130 EC satisfies all the requirements that arise in traditional and modern carpentry: cross and rip cuts in wood or insulating materials are easily executed thanks to the availability of appropriate accessories.
• Nothing is left to chance as far as safety is concerned: the MKS 130 EC features a motor brake and a self-closing saw guard. Among the other safety features, the on/off switch has an integrated starting lockout button.
• The desired cutting depth is easily set with a control wheel and highly legible scale. The nuisance of doublechecking dimensions is a thing of the past.
• Ergonomic, ideally positioned handles offer supreme operating ease and allow the work to be performed efficiently in every situation.
• Continuously variable speed control for individual requirements and applications.

Includes

• 24T Universal Carbide Blade
• Parallel Guide Fence
• Allen Key
• 32.8 ft Cord

Specifications

• Cutting depth at 0° off track: 1-15/16 to 5-1/16in
• Cutting depth at 45° off track: 1-7/16 to 3-11/16in
• Cutting depth at 60° off track: 15/16 to 2-1/2in
• Cutting depth at 0° on track: 1-11/16 to 4-7/8in
• Tilt range: 0 to 60°
• Saw blade diameter: 12-15/16in
• Nominal speed - no load: 1,000 to 2,000 rpm
• Motor: 120 V or 240 V / 60 Hz
• Current: 20.5 A
• Weight: 31 lbs

Applications

• Cross-cutting and rip cuts
• Bevel cuts up to 60°
• General joining work, birdsmouth cuts
• Compatible materials include solid wood, laminated beams, insulating materials, composite boards
