Features:
- Powerful 1 HP motor
- Drill press with limit switch protection
- Line interruption electro-mechanical switch needs a restart after a power failure
- Spindle is supported by high quality ball bearings
- Cast-iron pulleys reduce vibrations
- 45° tilting table for angular drilling
- Non-slip rubber feed handles
- 12 speeds
- Line interruption electromechanical switch and safety guard with limit switch protection
- Light socket incorporated into drill press head (standard light bulb not included)
Specifications:
- CAPACITY: 1-1/4"
- CHUCK SIZE: 3/4"
- SWING: 22"
- STROKE: 4-3/4"
- MAX. DISTANCE FROM CHUCK TO TABLE: 21-3/4"
- MAX. DISTANCE FROM CHUCK TO BASE: 41-7/8"
- TABLE SIZE: 18-3/4" x 16-1/4"
- SIZE OF T-SLOT ON TABLE: 5/8"
- SPINDLE TAPER: MT#4
- QUILL DIAMETER: 75 mm
- SPEEDS: (RPM)12 (180 - 4,200)
- MOTOR: 12.5 Amp. @ 110V, 6.25 Amp. @ 220V
- VOLTAGE: 110V/220V, 1 phase, 60Hz
- PRE-WIRED AT: 110V
